Multi Grade Filter (MGF) in Water Treatment: Working Principle, Process & Benefits

Multi Grade Filter (MGF) in Water Treatment: Working Principle, Process & Benefits

Understand how Multi Grade Filters (MGF) improve water quality by removing suspended solids, turbidity, and sediments in industrial and commercial water treatment systems.

What is Multi Grade Filter (MGF)?

MGF stands for Multi Grade Filter.

A Multi Grade Filter is a water filtration system designed to remove suspended solids, turbidity, dust, and sediment particles from water using multiple layers of filtration media.

The filter contains different grades and sizes of media arranged in layers to achieve effective filtration.

MGF systems improve water quality and protect downstream equipment such as:

RO membranes
Activated Carbon Filters
Water softeners
Pumps and valves

Why is MGF Used in Water Treatment?

Raw water may contain:

Sand particles
Dust
Silt
Suspended solids
Turbidity-causing impurities

If these impurities are not removed, they can:

Damage RO membranes
Reduce filtration efficiency
Increase maintenance costs
Cause clogging in pipelines and equipment

MGF systems help remove these impurities efficiently.

Multi Grade Filter Working Principle

The Multi Grade Filter works on the principle of depth filtration.

Water passes through multiple layers of filter media with different particle sizes.

Larger particles are trapped in the upper layers, while finer particles are removed in deeper layers.

This improves filtration efficiency and increases dirt holding capacity.

Multi Grade Filter Working Process

1. Water Inlet

Raw water enters the Multi Grade Filter vessel under pressure.

2. Filtration Through Media Layers

Water passes through different filtration media layers such as:

Pebbles
Gravel
Coarse sand
Fine sand

Each layer removes different sizes of suspended particles.

3. Removal of Suspended Impurities

The filter removes:

Dust
Sand
Turbidity
Suspended solids
Sediment particles

4. Clean Water Outlet

Filtered water exits the vessel with improved clarity and reduced turbidity.

Components of Multi Grade Filter

A typical MGF system consists of:

FRP or MS pressure vessel
Multi-grade filtration media
Multiport Valve (MPV) or manual valves
Piping connections
Pressure gauges

Types of Multi Grade Filters

Automatic Multi Grade Filter

Operates automatically using control valves and automation systems.

Manual Multi Grade Filter

Requires manual operation for backwashing and filtration control.

Applications of Multi Grade Filter

MGF systems are widely used in:

RO Water Treatment Plants

Used as pre-treatment before RO systems.

Industrial Water Treatment

Removes suspended impurities from process water.

Commercial Buildings

Improves water quality for daily usage.

Wastewater Treatment Plants

Used before secondary and tertiary treatment systems.

Food and Beverage Industry

Provides cleaner process water.

Benefits of Multi Grade Filter

Removes suspended solids effectively
Improves water clarity
Reduces turbidity
Protects RO membranes and equipment
Improves filtration efficiency
Low maintenance and operating cost
Long service life

Backwashing in Multi Grade Filter

Over time, dirt accumulates inside the filter media.

Backwashing is performed to clean the filter.

During backwashing:

Water flow direction is reversed
Trapped particles are flushed out
Filter media gets cleaned

Regular backwashing improves filter performance and lifespan.

Multi Grade Filter vs Pressure Sand Filter

Both systems are used for filtration, but MGF provides better filtration efficiency because it uses multiple layers of graded media.
